ILSC PBTD-6-500-M
MFG #PBTD-6-500-M
UPC #78366908104
SKU #4280379
Product description
ILSC PBTD-6-500-M INSUL AL MECH (6) 600-4 MTG TUL CSA FACTORY NON-STOCK, NON-RETURNABLE
ILSCO® NIMBUS® Multi-Tap Connector, Type PBTM 2-Sided Entry 6-Port Dual Rated Insulated, Aluminum/Copper Conductor, Trough/Wire Way/Panel Installation, 600 VAC, Specifications: 4 AWG to 600 kcmil Wire, 3/8 in Hex, 5/16 in Mount Hole, 475 A, -45 to 90 deg C, Aluminum, 10.467 in L x 3.031 in W x 3.195 in H Dimensions
ILSCO® NIMBUS® Multi-Tap Connector, Type PBTM 2-Sided Entry 6-Port Dual Rated Insulated, Aluminum/Copper Conductor, Trough/Wire Way/Panel Installation, 600 VAC, Specifications: 4 AWG to 600 kcmil Wire, 3/8 in Hex, 5/16 in Mount Hole, 475 A, -45 to 90 deg C, Aluminum, 10.467 in L x 3.031 in W x 3.195 in H Dimensions
- ILSCO® NIMBUS® Multi-Tap Connector, Type PBTM 2-Sided Entry 6-Port Dual Rated Insulated, Aluminum/Copper Conductor, Trough/Wire Way/Panel Installation, 600 VAC, Specifications: 4 AWG to 600 kcmil Wire, 3/8 in Hex, 5/16 in Mount Hole, 475 A, -45 to 90 deg C, Aluminum, 10.467 in L x 3.031 in W x 3.195 in H Dimensions
- CONNECTOR MULTI-TAP AL/COPPER AL 600VAC
- Product Catalog Page(s)
MSDS
Specification Sheet
- CSA File No. LR-29601|UL 486A/486B|UL 453G|UL File No. E6207|PROP65: Cancer and Reproductive Harm - www.P65warnings.ca.gov
- Brand: ILSCO -ECM IndustriesAmperage Rating: 475 AApplication: Mountable Insulated Multi-Tap Connector Dual Side EntryColor: BlackConductor Range (Main/Primary): AL Solid (Primary, run, main, line):NA;CU Solid (Primary, run, main, line):NA;CU Stranded (Primary, run, main, line):600 kcmil - 4 Str;AL Stranded (Primary, run, main, line):600 kcmil - 4 StrConductor Range (Tap/Secondary): AL Solid (Secondary, tap, load):NA;CU Solid (Secondary, tap, load):NA;AL Stranded (Secondary, tap, load):NA;CU Stranded (Secondary, tap, load):NAConnection: MechanicalCountry of Origin: MXEnvironmental Conditions: Cold temperature rated to -45°CFinish: Tin PlatedInsulation: PlastisolMaterial: AluminumMounting Hole Spacing: 8.967 INNumber Of Conductors: 6Number Of Mounting Holes: 2Number Of Ports: 6Special Features: Dual Rated for Copper and Aluminum Connectors.;High dielectric strength plastisol is chemical and UV resistant;Cold temperature rated to -45°C;Isolated mounting in trough, wire way or panelsStandard: CSA File No. LR-29601|UL 486A/486B|UL 453G|UL File No. E6207|PROP65: Cancer and Reproductive Harm - www.P65warnings.ca.govSub Brand: NimbusTemperature Rating: 90 °CType: PBTM:MOUNTABLE INS BLKVoltage Rating: 600 V
